Shandong Huaqi Automotive Technology Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm shacman f3000 pob tseg tsheb hauv Suav teb. Yog tias koj yuav mus rau cov lag luam wholesale classy shacman f3000 pob tseg tsheb hauv Suav teb, txais tos kom tau txais cov qauv dawb los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab tus nqi qis.
Technical Parameters
|
Qeb |
Parameter |
Specification |
|
Cov ntaub ntawv yooj yim |
Qauv No. |
SX3316DR426 |
|
Tsav hom |
8 × 4 (4 qag) |
|
|
Wheelbase |
1800 + 4175 + 1400 hli |
|
|
Zuag qhia tag nrho Dimensions (L × W × H) |
10.75 × 2.49 × 3.54 m |
|
|
Pob tseg Lub Cev Dimensions (Tswj) |
7.6 × 2.3 × 1.5 m (customizable) |
|
|
Qhov hnyav |
~ 15.4 tons |
|
|
Rated Payload |
~ 15.4 tons |
|
|
Gross Vehicle Weight (GVW) |
31 ton |
|
|
Txoj kev mus/tawm lub kaum sab xis |
17℃/ 24 degree |
|
|
Tsheb ciav hlau |
Cav Qauv |
Weichai WP12.375E50 (Inline 6-lub tog raj kheej) |
|
Kev khiav tawm |
11.596 L |
|
|
Max zog |
375hp ua |
|
|
Max Torque |
1800 N·m @ 1000 - 1400 rpm |
|
|
Emission Txuj |
Euro 5 |
|
|
Kev sib kis |
Fast 12JSD180T (12-ceev phau ntawv) |
|
|
Chassis |
Pem hauv ntej qag |
2 × 9-tuj muaj peev xwm |
|
Tsheb Axles |
2 × Hande 16-tuj ob qhov txo qis qis |
|
|
Tsheb Axle Ratio |
5.262 / 5.92 (hnyav-lub luag haujlwm nyiam) |
|
|
Ncej |
Muab ob npaug rau- txheej siab- lub zog steel |
|
|
Kev ncua |
Pem hauv ntej 10-nplooj, rear 12-nplooj ntau nplooj springs |
|
|
Tyre Loj |
12.00R20 16 Nws |
|
|
Lub Cev & Nres |
Khoom siv lub cev pov tseg |
U-zoo li tus / duab plaub siab- lub zog steel (pem teb: 8 - 10 hli, sab phab ntsa cov ntsiab lus) |
|
Lifting System |
Pem hauv ntej -mounted hydraulic system, max nqa lub kaum sab xis ~ 45 degree |
|
|
Nres System |
Dual -circuit air brake + ABS + WEVB cav nres |
|
|
Cab |
Hom |
F3000 flat-ru tsev cab, 4-point suspension |
Khoom zoo
Pov thawj & ntseeg tau Powertrain
Txais cov classic "Golden Power Chain": Weichai engine + Fast 12-speed manual transmission + Hande heavy-duty rear qag. Lub zog qis-ceev torque, kev ua haujlwm ruaj khov, ua haujlwm siab, thiab kho yooj yim.
Heavy -lub luag hauj lwm Reinforced Chassis
Muab ob npaug rau- txheej siab- lub zog steel ncej, txhawb nqa nplooj hlav caij nplooj ntoos hlav, muaj peev xwm thauj khoom siab, muaj zog tiv thaiv -twist muaj peev xwm, haum rau ntev - lub sij hawm hnyav- kev ua haujlwm ntawm txoj kev ntxhib.
Off-kev ua tau zoo heev
High av clearance, loj mus kom ze thiab tawm cov ces kaum, muaj zog passability nyob rau hauv kev tsim kho qhov chaw, mines thiab av nkos txoj kev.
Tus nqi siab -Kev ua tau zoo
Tus nqi qis dua, cov khoom siv dav dav, cov nqi tu qis, tus nqi tuaj koom siab, thiab xa rov qab sai ntawm kev nqis peev.
Tswv yim & Durable Structure
Yooj yim thiab ruaj khov sab hauv, cov khoom siv hluav taws xob tsawg tsawg, muaj zog tiv thaiv- plua plav thiab tiv thaiv- kev co. Lub cargo lub cev yog ua los ntawm siab -lub zog steel, hnav-resistant thiab cuam tshuam-resistant.
Efficient Hydraulic Lifting System
Pem hauv ntej -mounted hydraulic lub tog raj kheej, ruaj khov lifting, ceev unloading, siab ua hauj lwm efficiency.
Cov ntawv thov tseem ceeb
- Kev thauj mus los hauv mining: Coal, ore, pob zeb thauj hauv mines thiab quarries
- Nroog muck & siv pov tseg thauj
- Kev tsim kho vaj tse: Earthwork, gravel, backfill cov ntaub ntawv rau txoj kev, txuas hniav, dams
- Sand & gravel tsev cov ntaub ntawv thauj mus los
- Cov khoom thauj ntau thiab luv - mus rau - nruab nrab nrug hnyav load logistics
Tej Teeb Meem
Cav
Tsis muaj zog, qaug zog nce siab
Cav overheating / dej kub
Cov pa luam yeeb dub, txawv txav ceev
Kev siv roj ntau
01
Chassis & Suspension
Cov log tsheb txawv txav, tsheb sib txawv
Steering log co
Tsheb qag nrov nrov los yog overheating
Nplooj nplooj tawg lossis U-bolt loosening
02
Nres System
Tsis muaj zog braking, ntev braking nrug
Huab cua xau hauv huab cua Circuit Court
Nres rub los yog xauv
Tsis zoo li braking nrov
03
Hydraulic Lifting System
Kev nqa qeeb lossis tsis ua haujlwm nqa
Tsis siv neeg poob ntawm lub cev pov tseg
Kev vibration lossis suab nrov txawv txav thaum nqa
Hydraulic roj to
04
Hluav taws xob & Cab
Cab vibration thiab suab nrov txawv txav
Teeb, wiper lossis horn malfunction
Nquag fuse tshuab
Instrument txawv txav zaub
05
Cim npe nrov: Shacman f3000 dump truck, Tuam Tshoj shacman f3000 dump truck manufacturers, lwm tus neeg, Hoobkas
